| Measuring Ranges | -1/0 … 0.35/40 bar |
| Accuracy | 0.2% FS/year (non-cumulative) |
| Process Temperature | -40°C … +125°C |
| Ambient Temperature | -40…+70 °C (–40…+158 °F) |
| Lifetime | Designed >100M cycles |
| Wetted Parts | Stainless Steel 316L |
| Electrical Connection | Plug connection or fixed cable |
| Protection | IP67 (IP65 connection plug type A and C) |
| Approvals | CE, conforms to European Pressure Directive, Fully RoHS compliant,UL recognized file # EX16137 |
| Weight | 35 grams |
| Voltage Output | 0 … 5/10; 1 … 5/6V; 0.5 … 4.5V |
| Output Signal | 3-wire, linear characteristic curve |
| Current Output | 4 … 20 mA |
| Output Signal | 2-wire, linear characteristic curve |
